6W ±12V/230mA Isolated DC/DC Converter 9-18Vin, n=80%, Viso=500VDC

Index Ropla CIN0069
Manufacturer's part number EC4CE04
Manufacturer Cincon
Data sheet /cin/ec4ce.pdf ec4ce.pdf (647,99KB)
Product group DC/DC Converters
Manufacturer Cincon
Number of Outputs 2
Power 6.0W
Series EC4CE
Output Voltage 1 12V
Output Current 1 230mA
Input Voltage 9.0V ~ 18V
Isolation Voltage 500VDC
Output Voltage 2 -12V
Output Current 2 230mA
Efficiency 80%
Ripple/Noise 1% p-p
Type Isolated
Package/Case C
Mounting Style THT
Tₘᵢₙ -25°C
Tₘₐₓ 71°C
Packaging Tube
Collective package -/6/42 pcs
Weight 51.000000 g
Weight of the collective package -/306 g/2,142 g
Customs number 85423990
EC4CE SERIES 5-6 WATT 2:1 INPUT RANGE DC-DC CONVERTERS

FEATURES:

• 5-6W Isolated Output
• 2" x 2" Case
• Regulated Outputs
• Efficiency to 82%
• Pi Input Filter
• Continuous Short Circuit Protection
