	Index Ropla	PDC5106
	Manufacturer's part number	CSS0214P-5R6N-LRH
	Manufacturer	PDC
	Data sheet	css0214p.pdf (247,99KB)

Product group	Chokes
Manufacturer	PDC
Product Type	Inductor
Series	CSS0214P
Technology	Wire Wound
Protection style	yes
Inductance	5.6µH
Tolerance	30%
Maximum DC Current I_RMS	980mA
Maximum DC Resistance R_DC	188.0mΩ
Test Frequency f_L	100kHz
Saturation Current I_SAT	950mA
Product category	Shielded Power Inductor
Package/Case	3.2x3.2x1.55
Mounting Style	SMD
Packaging	Reel 7"
Tₘᵢₙ	-30°C
Tₘₐₓ	100°C

Collective package	1,000/3,000/15,000 pcs
Customs number	85041020

RoHS	pdc_rohs_coil.pdf (414,91KB) product compliant with the RoHS Directive
REACH	pdc_reach_coil.pdf (0,99MB)

1,000	pcs	Minimum order quantity
1,000	pcs	Multiple
1,000/3,000/15,000	pcs	Collective package
