30W 12V/2.5A Isolated DC/DC Converter, 9-36Vin, n=90.5%, Viso=1500VDC


	Index Ropla	CIN0475
	Manufacturer's part number	EC9BW-24S12
	Manufacturer	Cincon
	Data sheet	ec9bw.pdf (248,83KB)

EC9BW SERIES 30 WATT 4:1 INPUT DC-DC CONVERTERS

FEATURES:

• 30W Isolated Output
• Efficiency to 92%
• 2’’x1’’ Six-Sided Shield Metal Case
• 4:1 Input Range
• Regulated Outputs
• Fixed Switching Frequency
• Input Under Voltage Protection
• Over Current Protection
• Remote On/Off
• Continuous Short Circuit Protection
• No Tantalum Capacitor Inside
• CE Mark Meets 2004/108/EC
• Safety Meets UL60950-1, EN60950-1, and IEC60950-1

RoHS	cincon_rohs.pdf (400,48KB) product compliant with the RoHS Directive
REACH	cincon_reach.pdf (385,29KB)
CE	ce_ec9bw.pdf (1,33MB)

Product group	DC/DC Converters
Manufacturer	Cincon
Number of Outputs	1
Power	30W
Series	EC9BW
Output Voltage 1	12V
Output Current 1	2.5A
Input Voltage	9.0V ~ 36V
Isolation Voltage	1500VDC
Efficiency	90.5%
Ripple/Noise	100mV p-p
Type	Isolated
Package/Case	B
Mounting Style	THT
Remote On/Off Logic	positive
Tₘᵢₙ	-40°C
Tₘₐₓ	85°C
Packaging	Tube

Collective package	-/12/84 pcs
Weight	35.000000 g
Weight of the collective package	-/420 g/2,940 g
Customs number	85423990

1	pcs	Minimum order quantity
1	pcs	Multiple
-/12/84	pcs	Collective package
