Ropla Elektronik Sp. z o.o. | Stock | Cincon - EC4BU-05S33 - 8.25W 3.3V/2.5A Isolated DC/DC Converter, 4.7-9Vin, n=87%, Viso=1500VDC

8.25W 3.3V/2.5A Isolated DC/DC Converter, 4.7-9Vin, n=87%, Viso=1500VDC


	Index Ropla	CIN0182
	Manufacturer's part number	EC4BU-05S33
	Manufacturer	Cincon
	Data sheet	ec4bu.pdf (242,89KB)

EC4BU SERIES 10 WATT 2:1 INPUT DC-DC CONVERTERS

FEATURES:

• 10W Isolated Output
• Efficiency to 87%
• 2:1 Input Range
• Regulated Outputs
• Fixed Switching Frequency
• Input Under Voltage Protection
• Over Current Protection
• Conductive EMI Meets EN55022 Class A
• Continuous Short Circuit Protection
• Without Tantalum Capacitors Inside
• CE Mark Meets 2004/108/EC
• Safety Meets UL60950-1, EN60950-1 and IEC60950-1

RoHS	cincon_rohs.pdf (400,48KB) product compliant with the RoHS Directive
REACH	cincon_reach.pdf (385,29KB)
CE	ce_ec4bu.pdf (83,05KB)

Product group	DC/DC Converters
Manufacturer	Cincon
Number of Outputs	1
Power	8.25W
Series	EC4BU
Output Voltage 1	3.3V
Output Current 1	2.5A
Input Voltage	4.7V ~ 9.0V
Isolation Voltage	1500VDC
Efficiency	87%
Ripple/Noise	100mV p-p
Type	Isolated
Package/Case	B
Mounting Style	THT
Remote On/Off Logic	positive
Tₘᵢₙ	-40°C
Tₘₐₓ	85°C
Packaging	Tube

Collective package	-/12/84 pcs
Weight	35.000000 g
Weight of the collective package	-/420 g/2,940 g
Customs number	85423990

1	pcs	Minimum order quantity
1	pcs	Multiple
-/12/84	pcs	Collective package
